Development of small and energy-saving desert brackish water membrane desalination process and equipment development

Publish time:2023-09-07 08:25

datasets

28268

views

downloads

374.2 MiB

file size

The data results of the national key R&D program "Development of Small and energy-saving Desert Bracky water membrane Desalination Process and Equipment Development (2017YFE0114200)", chaired by Associate Professor Du Runhong of Tianjin University of Technology, are officially released on the National Cryosphere Data Center (www.ncdc.ac.cn) and are available for download. A total of 22 data sets have been released in this project, including data on the change of lake water recovery rate with lake salt content, total dissolved solids of lake water, nanofiltration hardness removal rate of lake water, water quality data, concentrated brine treatment data of lake water desalination system, sludge density index data of lake water pretreatment, etc. In order to solve the problem of brackish water desalination in arid and semi-arid areas, a reasonable process and equipment design basis are proposed.

Data set of overall desalination rate of Tianjin Jinhai Lake desalination system (July September 2020)

After precision filtration ultrafiltration pretreatment, the water of Jinhai lake is desalted by reverse osmosis / nanofiltration system. The desalination rate of the desalination system under different mixed loading modes and different operating pressures was investigated. The desalination system adopts commercial polyamide 4040 roll type nanofiltration and reverse osmosis membrane m...

file size:: 110.1 KiB
visits:: 1177
created time:: 2021-10-20

Model Atlas of Tianjin Jinhai Lake desalination system (May 30, 2021)

Three model drawings of the complete set of Tianjin Jinhai Lake desalination system drawn by UG NX 12.0 software, including front view, Southeast axonometric map and northeast axonometric map.

file size:: 227.7 KiB
visits:: 1095
created time:: 2021-10-20

Data set of produced water quality of Tianjin Jinhai Lake desalination system (July September 2020)

The produced water samples of Jinhai lake water collected in 2020 after precision filtration ultrafiltration pretreatment and desalination by reverse osmosis / nanofiltration system, and the produced water quality report obtained by the third-party testing organization national seawater and brackish water conservancy product quality supervision and inspection center and Institute of R...

file size:: 4.5 MiB
visits:: 1646
created time:: 2021-10-20

Process flow diagram of Tianjin Jinhai lake water desalination system (May 30, 2021)

According to the field experimental process, the process flow chart of Tianjin Jinhai Lake desalination system is drawn by AutoCAD software.

file size:: 168.1 KiB
visits:: 1115
created time:: 2021-10-20

Total dissolved solids data set of Tianjin Jinhai Lake (2017-2020)

From 2017 to 2020, water samples from Jinhai Lake in Tianjin were collected and obtained according to the test method and process specified in the standard test methods for sensory properties and physical indexes of drinking water GB / t5750.4-2006 (8.1). The measurement is accurate to two decimal places. From July 2017 to November 2020, the highest content of total dissolved solids i...

file size:: 9.5 KiB
visits:: 1514
created time:: 2021-10-19

Variation data set of salt content in produced water of Tianjin Jinhai Lake desalination system with salt content in lake water (July November 2020)

The water of Jinhai lake is pretreated by precision filtration ultrafiltration and desalted by reverse osmosis / nanofiltration system. After the pressure and flow rate stabilize for half an hour, record the salt content of produced water. The precision filtration system adopts filtration accuracy of 5 μ M bag filter element and melt blown filter element are connected in series, and th...

file size:: 158.7 KiB
visits:: 1343
created time:: 2021-10-28

Proceedings of small-scale high-efficiency and energy-saving desert brackish water membrane desalination process development and equipment development project (2018-2021)

file size:: 19.0 MiB
visits:: 1161
created time:: 2021-10-20

Concentrated brine treatment data set of Tianjin Jinhai Lake desalination system (July 20, 2019 - October 30, 2020)

The hardened concentrated brine is pumped into bipolar membrane electrodialysis assembled from cation exchange membrane (CMB), anion exchange membrane (ACM) and bipolar membrane (bp-1e) produced by astom company of Japan through circulating pump (mp-70rz, xinxishan). The volume of storage tanks in each chamber is 4L. Steady cycle for half an hour before starting the power supply to el...

file size:: 207.1 KiB
visits:: 1252
created time:: 2021-10-20

Data set of variation of water recovery rate of Tianjin Jinhai Lake desalination system with salt content of lake water (July November 2020)

The water of Jinhai lake is pretreated by precision filtration ultrafiltration and desalted by reverse osmosis / nanofiltration system. After the pressure and flow rate stabilize for half an hour, record the water recovery rate. The precision filtration system adopts filtration accuracy of 5 μ M bag filter element and melt blown filter element are connected in series, and the operating...

file size:: 88.9 KiB
visits:: 1238
created time:: 2021-10-28

Data set of fresh water production and overall water recovery rate of Tianjin Jinhai Lake desalination system (July September 2020)

After precision filtration ultrafiltration pretreatment, the water of Jinhai lake is desalted by reverse osmosis / nanofiltration system. The water yield and water recovery of the desalination system under different mixed loading modes and different operating pressures are mainly investigated. After the pressure and flow rate are stable for half an hour, record the water production of...

file size:: 103.4 KiB
visits:: 1197
created time:: 2021-10-20
