Soil erosion data set of national key prevention area in the northern foot of Yinshan Mountain in 2022

English name

CSTR

CSTR:11738.11.NCDC.HHSTBC.DB4005.2023

DOI

10.12072/ncdc.hhstbc.db4005.2023

Share type

Apply to Access

Category

Soil and Water Conservation

contributors

Datasets description

 <p>In 2022, the soil erosion data set of the national key prevention area at the northern foot of Yinshan Mountain includes the soil erosion statistical tables of Darhan maoming'an United banner, Wulate Middle Banner, Wulate rear banner, Siziwang Banner, Sunite Left Banner and Sunite Right Banner in Inner Mongolia Autonomous Region in 2022, which are processed based on satellite remote sensing image with spatial resolution of 2m, and saved in xlsx format, The data are named in the form of "key control area + year + soil erosion statistical table", such as“ ×× Key governance areas ×× Statistical table of soil erosion in 2000. Soil erosion intensity can be divided into 6 grades: Micro erosion, light erosion, moderate erosion, strong erosion, very strong erosion and severe erosion.</p>

Base information

collect time	2021/01/01 - 2021/12/31
collect place	National key prevention area at the northern foot of Yinshan Mountain
data size	57.0 KiB

Data source description

                                              <ol>

The data sources of land use are ZY-3 and Gao FEN-1 satellite images, which are mainly obtained from the information center of the Ministry of water resources. 2. Vegetation data sources are ZY-3 and Gao FEN-1 satellite images, which are mainly obtained from the information center of the Ministry of water resources. 3.1:50000 DEM is mainly obtained from the information center of the Ministry of water resources.

Data processing method

                                              <ol>

Based on the thematic maps of land use, vegetation coverage and slope, the soil erosion intensity was graded by ArcGIS software. 2. The land use processing method is based on ecognition software platform, using the method of object-oriented computer automatic classification and manual visual interpretation to extract the land use data of the study area year by year. Finally, three methods are used to verify the accuracy of the data: field sample point survey, high-resolution image recognition and Google Earth sample point recognition. 3. The processing method of vegetation coverage is based on remote sensing estimation, and the normalized vegetation index (NDVI) is used to estimate the vegetation coverage by pixel dichotomy model. First, the NDVI of each pixel is calculated by using the near-infrared and red band data of multispectral images. Then, the model is used to calculate the vegetation coverage of the whole region, and the vegetation coverage is classified according to the classification rules. Finally, the land use type data obtained from remote sensing interpretation and the vegetation coverage data obtained from remote sensing estimation are used for superposition operation, The vegetation coverage information of each pixel was obtained. 4. Slope data processing method is based on 1:50000 DEM extraction.

Data quality description

                                                      <ol>

Remote sensing images are preprocessed by radiation correction, orthorectification, fusion and mosaic. 2. The actual surface area corresponding to the minimum spot area is not less than 0.1 h ^, the polygons have no overlap, no gap, and the spot attributes have no vacancy or redundancy. 3. Before the remote sensing image interpretation, the remote sensing image, typical investigation and field comparison methods are used to establish the remote sensing interpretation marks of forest and grass sample plots. 4. Based on remote sensing images, combined with interpretation marks, extract land use types. 5. Review of interpretation results: no less than 5% of the total map spots shall be selected for verification. 6. The number and results of field verification samples meet the requirements of technical specification for remote sensing monitoring of soil and water conservation (sl592-2012). For verification spots, 10% are selected as verification samples for field verification.

Citations and annotations

In order to protect the rights and interests of the platform's scientific and technological resources, expand the services of the platform center, and enhance the application potential of scientific and technological resources, resource users are requested to mark and quote the research results (including published papers, treatises, data products, unpublished research reports, data products, etc.) generated by the use of resources in the following manner.

For the achievements published in English, please refer to the following specifications： The dataset is provided by National Cryosphere Desert Data Center. (http://www.ncdc.ac.cn).

Data reference

. Soil erosion data set of national key prevention area in the northern foot of Yinshan Mountain in 2022. National Cryosphere Desert Data Center(http://www.ncdc.ac.cn), 2023. https://cstr.cn/CSTR:11738.11.NCDC.HHSTBC.DB4005.2023.
. Soil erosion data set of national key prevention area in the northern foot of Yinshan Mountain in 2022. National Cryosphere Desert Data Center(http://www.ncdc.ac.cn), 2023. https://www.doi.org/10.12072/ncdc.hhstbc.db4005.2023.

EndnoteEN BibtexEN RISEN

license agreement

This work is licensed under CC BY 4.0 (Creative Commons Attribution 4.0 International License).
