This dataset is based on the visualization test results of the core wall, impermeable wall, and curtain quality of Pianga Reservoir using visualization repair equipment, including electromagnetic wave signal data during the testing process and visualization detection results of quality.
This dataset is based on the analysis and inversion of electromagnetic wave signals to evaluate the quality of heart walls, impermeable walls, and curtains.
The dataset consists of CSV and BMP files, which can be viewed or edited through various text and image software.
In this dataset, there are two files: "Raw Data. csv" and "Interpreted Data. bmp". "Raw Data. csv" includes: 5-6.csv, f7j8.csv, f9j8.csv, f9j10.csv, f10j11.csv; The "Interpreted Data. Bmp" includes: f5-j6_CT-wave speed.bmp, f7j8_CT-wave speed.bmp, f9j8_CT-wave speed.bmp, f9j10_CT-wave speed.bmp, f10j11_CT-wave speed.bmpp. The CVS file contains: serial number, validity, arrangement, transmitting station, receiving station, starting point X, starting point Y, ending point X, ending point Y, plane length, travel time ns, wave velocity m/ns, constant, amplitude ratio, skin depth, radiation, attenuation (ln), Data8, transmitting Cos.
This data was independently developed by Nanjing Water Conservancy Science Research to test the quality of the core wall, impermeable wall, and curtain of the Pianga Reservoir using a high dam deep buried disease visualization repair equipment. The test results were verified by on-site core sample results.
Open the collected data through the project file, use the equipment's built-in automatic calculation model to invert the electromagnetic wave signal data, and obtain the visualization results of the reservoir's core wall, impermeable wall, and curtain.
Open the collected data through the project file, use the equipment's built-in automatic calculation model to invert the electromagnetic wave signal data, and obtain the visualization results of the reservoir's core wall, impermeable wall, and curtain.
| # | number | name | type |
| 1 | 2021YFC3090103 | Technical equipment for detection, diagnosis and danger elimination of deep-buried diseases in high earth-rock dams | National key R & D plan |
