CSTR:11738.11.ncdc.SRIPE.db1706.2022
10.12072/ncdc.SRIPE.db1706.2022
The low-temperature triaxial compressive strength simulation experiment of frozen soil was carried out in Qingdao, Shandong Province in 2018 and 2019. The observation elements include sample density, ambient temperature, confining pressure, compressive strength, peak strength, etc. The data collection time range is from April 20, 2018 to April 20, 2019. The low-temperature triaxial experimental device is used to measure the triaxial compressive strength of Mohe frozen soil and Dongying frozen soil under different buried depths, temperatures and confining pressures. It is used to study the variation law of mechanical parameters of frozen soil layer with temperature and confining pressure, and establish the prediction model of geotechnical mechanical parameters of frozen soil layer.
Experiment, self generation
The data is collected by the servo controlled low temperature conventional triaxial test system of China University of petroleum. The technical parameters are as follows: 1. Maximum axial force: 1000KN; 2; 2. Accuracy of test force: ± 1%； 3. Resolution of test force: 1 / 120000; 4. Maximum displacement of piston: 100 mm; 5. Displacement accuracy: ± 1%； 6. Displacement resolution: 1 / 100000; 7. Axial deformation measurement range: 0-8mm; 8. Radial deformation measurement range: 0-4mm; 9. Deformation measurement accuracy: ± 1%； 10. Deformation resolution: 1 / 100000; 11. Maximum confining pressure: 100MPa; 12. Confining pressure accuracy: ± 2%； 13. Confining pressure resolution: 1 / 60000.
Good data quality
| # | number | name | type |
| 1 | 2016YFC0303300 | National key R & D plan |
