Experimental data set for thermal insulation performance evaluation of vacuum thermal insulation casing (March August 2019)
  • 2022/02/25 22:41
  • 1490
  • 3
English name
Experimental data set for thermal insulation performance evaluation of vacuum thermal insulation casing (March August 2019)
CSTR
CSTR:11738.11.ncdc.SRIPE.db1709.2022
DOI
10.12072/ncdc.SRIPE.db1709.2022
Share type
Online
Category
Others
source site
Study on key drilling technology in polar cold sea
contributors
Gao deli
Datasets description

    In 2019, a low-temperature environmental insulation performance evaluation experiment was conducted on vacuum thermal insulation sleeves to analyze the temperature distribution characteristics of the insulation sleeve axis at different environmental temperatures. The observation elements include environmental temperature, circulating fluid temperature, vacuum degree, etc. The data resource collection time range is from March 20, 2019 to August 20, 2019. The surface temperature distribution of the vacuum insulation casing under different environmental temperatures and circulating fluid temperatures is measured using a vacuum insulation casing protection performance testing system to establish a heat transfer model for the vacuum insulation casing wellbore.

Base information
collect time 2019/03/20  -  2019/08/20
collect place Qingdao City, Shandong Province
data size 50.5 KiB
data format Excel
Coordinate system
Data thumbnail
Data source description

    Experimental experiments, independently generated.

Data processing method

    The instruments used for data collection include temperature sensors and intelligent patrol detectors. Technical parameters: 1. Temperature sensor measurement range -80 ℃ -60 ℃; 2. Measurement accuracy of 0.01 ℃.

Data quality description

    The data quality is good.

Project information
# number name type
1 2016YFC0303300 National key R & D plan
Citations and annotations
In order to protect the rights and interests of the platform's scientific and technological resources, expand the services of the platform center, and enhance the application potential of scientific and technological resources, resource users are requested to mark and quote the research results (including published papers, treatises, data products, unpublished research reports, data products, etc.) generated by the use of resources in the following manner.

For the achievements published in English, please refer to the following specifications： The dataset is provided by National Cryosphere Desert Data Center. (http://www.ncdc.ac.cn).

Data reference
  1. Gao deli. Experimental data set for thermal insulation performance evaluation of vacuum thermal insulation casing (March August 2019). National Cryosphere Desert Data Center(http://www.ncdc.ac.cn), 2022. https://cstr.cn/CSTR:11738.11.ncdc.SRIPE.db1709.2022.
  2. Gao deli. Experimental data set for thermal insulation performance evaluation of vacuum thermal insulation casing (March August 2019). National Cryosphere Desert Data Center(http://www.ncdc.ac.cn), 2022. https://www.doi.org/10.12072/ncdc.SRIPE.db1709.2022.
license agreement
Creative Commons License   This work is licensed under a Creative Commons Attribution 4.0 International License.
# title file size
1 _ncdc_meta_.json 3.6 KiB
2 真空隔热套管隔热性能评价实验数据集.xlsx 28.3 KiB
3 真空隔热套管隔热性能评价实验数据集_说明文档.docx 22.2 KiB
