The infrared temperature and water surface temperature observation system of Erba reservoir is set up to provide water surface temperature data for aviation TASI, widas and L-band flights.
Observation site: the Erba reservoir, 14km east of Zhangye City and next to Erba village, Jiantan Town, Ganzhou District, is selected as the observation point. Coordinates of the observation point: 38 ° 54'57.14 "n, 100 ° 36'57.39".
Measuring instrument: the observation contents include a si-111 infrared temperature probe perpendicular to the water surface and a si-111 infrared temperature probe observing the sky at a zenith angle of 35 degrees due south (the instrument was newly purchased in 2012, the default surface emissivity was 1 when it was delivered from the factory, and blackbody calibration was not carried out during the test). Two 0cm109ss-l temperature sensors floating below the water surface, data acquisition is Campell cr-1000, automatic acquisition, GPRS wireless transmission to the comprehensive collection system. The probe frame is 3M high and the offshore distance is 3.4m.
Measurement time: the instrument starts normal observation from May 27, 2012 to September 27, 2012, continuously observes for 24 hours, records data once in 5 seconds, and outputs two groups of values in 5 seconds and 1 minute.
Data content: vertical water surface temperature (tart)_ Sur, without correction of surface specific emissivity and background temperature), sky temperature (tart)_ ATM, without sky background specific emissivity correction), water surface 0cm directly measured temperature (water t)_ 1，WaterT_ 2）。 The data is finally stored as an independent text file for one day. The data naming method is: data format + observation point name + data sampling time + date + time. Dat. For detailed data header information, see the data header description in the data
14km east of Zhangye City, the Erba reservoir next to Erba village, Jiantan Town, Ganzhou district is used as the observation point.
It includes a si-111 infrared temperature probe perpendicular to the water surface and a si-111 infrared temperature probe for sky observation with a zenith angle of 35 degrees due to the South (the instrument was newly purchased in 2012, the default surface emissivity was 1 when it was delivered from the factory, and blackbody calibration was not carried out during the test). Two 0cm109ss-l temperature sensors floating below the water surface, data acquisition is Campell cr-1000, automatic acquisition, GPRS wireless transmission to the comprehensive collection system. The probe frame is 3M high and the offshore distance is 3.4m
Vertical water surface temperature (tart)_ Sur, without correction of surface specific emissivity and background temperature), sky temperature (tart)_ ATM, without sky background specific emissivity correction), water surface 0cm directly measured temperature (water t)_ 1，WaterT_ 2）。
| # | number | name | type |
| 1 | 91125004 | other |
